YMAE Air - Cooled DC Inverter Scroll Chiller
Range 12TR to 38.4TR
High efficiency:
BLDC Fan: The fan blades have been aerodynamically optimized for streamlined style to deliver extraordinarily low operation noise. The high-efficiency electronically commutated DC brushless BLDC motor regulates fan using a stepless speed method. The fan blades and motor align perfectly to deliver great low energy consumption.
Brazed Plate Heat Exchanger (BPHE): A stainless steel high-efficiency BPHE ensures optimum heat transfer efficiency. This provides superior performance and longer life cycle. In addition, the cross and counter flow design supplies water to the refrigerant circuit for full heat transfer with each refrigerant system, maximizing chiller efficiency, especially under part-load operation.
Fin Plate Coil: The airside heat exchanger features new corrugated fins with 7mm internal threaded copper tubes. The fins are made of hydrophilic aluminum foil to provide excellent hydrophilicity and corrosion resistance. The wave pattern design provides low airflow resistance, strengthens airflow disturbance and expands the heat transfer area. This makes for more effective heat exchange, which improves heat transfer efficiency.
Wide operating range:
YMAE has a wide operating range for full-year operation:
Cooling: Operating ambient temperature from 15°C to 48°C for superior cooling performance
Heating: Operating ambient temperature from 27°C to 43°C for stable heating performance that caters to different customer requirements
